C3 Controls 22mm IEC
Pushuttons Switches & Indicators
Electrical Components
Application Specific Controls
22mm IEC Push Buttons :
Flush, Momentary, Non-illuminated
Our U-Cup seal is infused with a Teflon coating to eliminate cracking when exposed to harsh conditions and acts like a squeegee to form a permanent watertight seal that meets Type 4/4X. Operators are UL Listed and are rated for Type 1, 2, 3, 3R, 4/4X, 12, 13 and IP65 applications, and meet global standards requirements.
PART NUMBER:W22PB-FG-10//
PRICE: $12.00
DESCRIPTION: PB, 22mm, Plastic(Type 4/4X), GREEN, FLUSH, 1 N.O.
PART NUMBER:W22PB-FR-10//
PRICE: $12.00
DESCRIPTION: PB, 22mm, Plastic(Type 4/4X), RED, FLUSH, 1 N.C.
PART NUMBER:W22PB-FK-10//
PRICE: $12.00
DESCRIPTION: PB, 22mm, Plastic(Type 4/4X), BLACK, FLUSH, 1 N.O.
PART NUMBER:W22PB-AFG-10//
PRICE: $13.00
DESCRIPTION: PB, 22mm, Aluminum (Type 4), GREEN, FLUSH, 1 N.O.
PART NUMBER:W22PB-AFR-10//
PRICE: $13.00
DESCRIPTION: PB, 22mm, Aluminum (Type 4), RED, FLUSH, 1 N.C.
PART NUMBER:W22PB-AFK-10//
PRICE: $13.00
DESCRIPTION: PB, 22mm, Aluminum (Type 4), BLACK, FLUSH, 1 N.O.
22mm IEC Push Buttons : Maintained :
Non-illuminated, 2-Position, Push-Twist Release
The linear push off twist to release style operator requires a TWIST for the OUT or ON position and a linear PUSH for the IN or OFF position. The twist mushroom cap is marked with arrows identifying the direction for the twist release. Molded bold white arrows (black arrows on yellow and white caps) indicate the 45-degree twist-to-release operation.
Operators are UL Listed and rated for Type 1, 2, 3, 3R, 4/4X, 12, 13 and IP65 applications, and meet global standards requirements.
PART NUMBER:W22PTR-YMR-01//
PRICE: $22.00
DESCRIPTION: PB, 22mm, Maintained, Red, Push-Twist Release, 1 N.C.
PART NUMBER:W22PTR-YMR-01/01/
PRICE: $27.50
DESCRIPTION: PB, 22mm, Maintained, Red, Push-Twist Release, 2 N.C.
PART NUMBER:W22PTR-YMY-01//
PRICE: $22.00
DESCRIPTION: PB, 22mm, Maintained, Yellow, Push-Twist Release, 1 N.C.
22mm IEC Selector Switches:
Non-Illuminated
Eliminating multiple cam configurations can save you time, inventory, money and ensure 100% accuracy. Selector switch configuration doesn't need to be a nightmare, with c3controls unique universal cam design, along with the proper contact block position. Reduce your SKU inventory - choose your circuit design, select a 2- or 3-position switch and add our snap-on contact blocks in the specified mounting position.
You can control up to 4 different circuits with just one selector switch. It's that simple with One-Cam.
Operators are UL Listed and rated for Type 1, 2, 3, 3R, 4/4X, 12, 13 and IP65 applications, and meet global standards requirements.
PART NUMBER:W22S2-HW-10/10-SERB
PRICE: $17.75
DESCRIPTION: 22mm IEC Selector Switches : Non-Illuminated ; Selector Switch ; 2 Pos. Maintained ; Standard ; White ; 2 Normally Open Contact Blocks .
PART NUMBER:W22S3-HW-10/10-SERB
PRICE: $17.75
DESCRIPTION: 22mm IEC Selector Switches : Non-Illuminated ; Selector Switch ; 3 Pos. Maintained ; Standard ; White ; 2 Normally Open Contact Blocks .
22mm IEC Pilot Lights:
Modular
Compact, thin design is also vibration resistant.Our seal is infused with a coating to eliminate cracking when exposed to harsh conditions and acts as a light reflector.
Rugged Lexan lenses provide better visibility and can resist high impact for reliable performance in most environments.
Operators are UL Listed and rated for Type 1, 2, 3, 3R, 4/4X, 12, 13 and IP65 applications, and meet global standards requirements.
PART NUMBER:W22PL-RMVDLR-WLR-SERB
PRICE: $44.90
DESCRIPTION: 22mm IEC Pilot Lights : Modular ; Pilot Light ; Multi-Voltage, Relampable ; 20V-240V AC or DC (Standard) ; LED Red ; Red .
PART NUMBER:W22PL-RMVDLG-WLG-SERB
PRICE: $44.90
DESCRIPTION: 22mm IEC Pilot Lights : Modular ; Pilot Light ; Multi-Voltage, Relampable ; 20V-240V AC or DC (Standard) ; LED Green ; Green .
PART NUMBER:W22PL-RMVDLA-WLA-SERB
PRICE: $44.90
DESCRIPTION: 22mm IEC Pilot Lights : Modular ; Pilot Light ; Multi-Voltage, Relampable ; 20V-240V AC or DC (Standard) ; LED Amber ; Amber .
22mm IEC Potentiometers:
Special Operators
Our single-turn Potentiometer Operators utilize standard 2 watt potentiometers with 6.4mm (1/4 ") bushing and 22.5mm (7/8 ") long slotted shafts. A 5/64 " allen wrench is required for installation. All c3controls 22mm operators are UL Listed and are rated Type 4/4X as standard for watertight and corrosion resistance. In addition, operators are also listed for Type 1, 2, 3, 3R, 12 and 13, and meet global standards requirements. PART NUMBER:22POTO10k-TBW
PRICE: $35.90
DESCRIPTION: 22mm IEC : Special Operators : Potentiometers ; Potentiometer ; 10k Potentiometer ; Polyester (Type 4X) ; Terminal Block installed and wired .
OPA-CAT-000-025/19A
PART NUMBER:22POTO5k-TBW
PRICE: $35.90
DESCRIPTION: 22mm IEC : Special Operators : Potentiometers ; Potentiometer ; 5k Potentiometer ; Polyester (Type 4X) ; Terminal Block installed and wired .
OPA-CAT-000-025/19B
PART NUMBER:22POTO2.5k-TBW
PRICE: $35.90
DESCRIPTION: 22mm IEC : Special Operators : Potentiometers ; Potentiometer ; 2.5k Potentiometer ; Polyester (Type 4X) ; Terminal Block installed and wired .
OPA-CAT-000-025/17C
PART NUMBER:22POTO1k-TBW
PRICE: $35.90
DESCRIPTION: 22mm IEC : Special Operators : Potentiometers ; Potentiometer ; 1k Potentiometer ; Polyester (Type 4X) ; Terminal Block installed and wired .
OPA-CAT-000-025/16D
PART NUMBER:22POTO
PRICE: $27.90
DESCRIPTION: 22mm IEC : Special Operators : Potentiometers ; Potentiometer ; Operator Only ; Polyester (Type 4X) ; Operator Only .
OPA-CAT-000-015/22A
Snap-on contact blocks
Snap-on contact blocks can be stacked 2 deep and up to 3 across for a total of 6 circuits.Color coded body for quick circuit identification.
Built-in self wiping cleaning action and high contact point pressure for low-level switching.
Rated A600 (7,200 VA Make and 720 VA Break), 600V AC Max., Maximum Continuous Thermal Current, Ith: 10A. Q600 (69 VA Make and Break), 600V DC Max., Maximum Continuous Thermal Current, Ith: 2.5A.
PART NUMBER:WNO-SERB
PRICE: $4.50
DESCRIPTION: CONTACT BLOCK, 22mm, N.O.
PART NUMBER:WNC-SERB
PRICE: $4.50
DESCRIPTION: CONTACT BLOCK, 22mm, N.C.
♦ Due to the wide product range we kindly recommend that you download the PDF document/product guide below and send us an E-mail with your selection of part numbers so we can accurately quote you pricing and delivery.
Complete Product Catalog Download
NOTE: We have other products available that are not displayed, so please do not hesitate to call or send us an e-mail.
